Plated, Painted or Natural (Read 1861 times)

RoadrunnerJD

Full 6 BBL/Six Pack Member

Road Runner, Catch
him if you can!

Posts: 594

Re: Plated, Painted or Natural
Reply #15 - 04/08/09 at 13:36:45

I recommend using the Eastwood zinc phosphate paint for your rear springs. I took mine apart, blasted them, painted them and installed new clamps. I left the clamps natural but painted them with a clear satin. See the previous photo. I think the Eastwood gave the springs the look that I wanted (I didn't want them to look painted).

IP Logged

A12_RuNNeR

4 BBL/Pack Member

SuPeRBee.....RuNNeR
Choose Your Weapon

Posts: 198

Re: Plated, Painted or Natural
Reply #16 - 04/10/09 at 10:34:36

Transmission mount ? I know the e bodys are yellow....

Here's what I "think" they are:

I'll begin and please just add to the list (or correct):

Front backing plates............ Zinc phosphate (Eastwood has it in a spray)
Rear backing plates............. Zinc Phosphate
Dana housing..................... Semi-flat black all over (there's no 3rd member)
Lower control arms.............. Cosmoline or goldish like the Holley Carbs
Upper control arms.............. natural or silver'ish
Rear springs....................... Natural Black from heat treating or black painted
Rear front spring hangers...... plain steel with undercoating sprayed from outside
Rear shackles......................natural plain steel
U Bolts & hardware ..............natural
Shock plates.......................black painted
Sway bar.......................... natural/(black heat treated look)
Sway bar brackets.............. Black painted
Sway bar links and bolts.......Zinc phosphate
Front Struts.......................natural steel more silver than blackened
Shocks..............................Gloss Black
Master cylinder...................Natural cast iron
Master cylinder cover........... yellow gold plated
Master cyl backing plate....... Gloss Black
Engine brackets...................
PS Pump............................
Spark plug wire separators and brackets
Fan...................................
K-Frame............................
Brake drums.......................
Emerg. Brake Cables.............
Torsion Bars....................... dipped in gloss black
Trans cross member............ dipped in gloss black
Transmission mount.............
Tie Rod ends......................
Steering link...................... Natural with a turquoise longitudinal inspection drip
Radiator......I like gloss black engine paint but you might want to go with underhood black
Front gravel Pan................

continue.........

« Last Edit: 04/10/09 at 11:56:36 by A12_RuNNeR »

Super Bee - WM23M9A270637 4-Speed
Road Runner - RM23M9A246385 4-Speed (949002)

"Yes, I'm a Big Fan of H Wheels on A12 Cars" Smiley

IP Logged

A12_RuNNeR

4 BBL/Pack Member

SuPeRBee.....RuNNeR
Choose Your Weapon

Posts: 198

Re: Plated, Painted or Natural
Reply #17 - 04/10/09 at 10:38:28

Quote from Coop on 04/08/09 at 08:45:43:

Scott,

BTW, we expect pics of your efforts from time to time. Cool

Coop, yes I will post some over in the 'New' project car section....but Dave hasn't given the car a name yet so I will wait for him to start a new thread.

I wasn't planning on doing an over-the-top resto like some of the other guys, I just want a nice driver that has the correct parts on it. But as per usual, where do you stop?

Super Bee - WM23M9A270637 4-Speed
Road Runner - RM23M9A246385 4-Speed (949002)

"Yes, I'm a Big Fan of H Wheels on A12 Cars" Smiley

IP Logged

Coop A12 Moderator ...so when does government's 'A12 welfare' start? Posts: 238	Re: Plated, Painted or Natural Reply #18 - 04/10/09 at 11:34:02 Ah yes...where to draw the line...when you figure that one out please let me know!
Back to top	Link to Slideshow...TURN THE MUSIC UP! http://albums.phanfare.com/isolated/F39VvCq5/1/1491997 IP Logged

96a12b 2 BBL/Pack Member Lift Off Hoods Forever! Posts: 57	Re: Plated, Painted or Natural Reply #19 - 04/10/09 at 18:11:19 Where do you draw the line? Where your wife tells you!
Back to top	IP Logged

A12

Full 6 BBL/Six Pack Member

Lift Off Hoods
Forever!

Posts: 1415

Re: Plated, Painted or Natural
Reply #20 - 04/11/09 at 19:11:19

Quote from RoadrunnerJD on 04/06/09 at 21:36:01:

Quote from A12 on 04/06/09 at 16:36:35:

Here's what I "think" they are:

I'll begin and please just add to the list (or correct):

Front backing plates............ Zinc phosphate (Eastwood has it in a spray)
Rear backing plates............. Zinc Phosphate
Dana housing..................... Semi-flat black all over (there's no 3rd member)
Lower control arms..............Cosmoline or goldish like the Holley Carbs
Upper control arms.............. natural or silver'ish
Rear springs....................... Natural Black from heat treating or black painted
Rear front spring hangers.... plain steel with undercoating sprayed from outside
Rear shackles.....................natural plain steel
Sway bar.......................... natural/(black heat treated look)
Sway bar brackets.............. Black painted
Sway bar links and bolts..... Zinc phosphate
Shocks..............................Gloss Black
Master cylinder...................Natural cast iron
Master cylinder cover........... yellow gold plated
Master cyl backing plate....... Gloss Black
Engine brackets...................
PS Pump
Spark plug wire separators and brackets
Fan
K-Frame
Torsion Bars
Tie Rod ends
Steering link
Radiator......I like gloss black engine paint but you might want to go with underhood black

continue.........

Mike:

How do you know if the corrections are correct? There are several expert articles ala Roger Gibson in Mopar Action, etc. We could end up with egg on our face here? Let's include photos of everything.

JD

JD, only posted this to "jump start" the thread............I knew I would get called out on some of this and I'm learning things every day

MikeR

IP Logged

Q5_Ed 5 BBL/Pack Member Lift Off Hoods Forever! Posts: 216	Re: Plated, Painted or Natural Reply #21 - 07/21/09 at 23:54:11 My turn detail so I'm bumping this back...
Back to top	FOUND- used rotisserrie IP Logged

maxwellwedge

Full 6 BBL/Six Pack Member

3 Dueces use gas -
Stay Thirsty My
Friends!

Posts: 266

Re: Plated, Painted or Natural
Reply #22 - 07/22/09 at 09:33:11

Leave the Eastwood stuff for the Chebbies!

Front backing plates............ Zinc phosphate
Rear backing plates............. Zinc Phosphate
Dana housing..................... Semi-flat black
Lower control arms..............Cosmoline
Upper control arms.............. natural - can put on some light Cosmoline
Rear springs....................... Natural Black from heat treating or black painted - I see more Natural
Rear front spring hangers.... plain steel with undercoating sprayed from outside
Rear shackles.....................natural plain steel
Sway bar.......................... BLACK Paint!
Sway bar brackets.............. Black painted
Sway bar links and bolts..... Zinc phosphate
Shocks..............................SEMI-Gloss Black
Master cylinder...................Natural cast iron
Master cylinder cover........... gold CAD plated - Zinc Phos Hold-Down strap and bolt
Master cyl backing plate....... Semi-Gloss Black
Engine brackets................... Dipped Black
PS Pump - Black
Spark plug wire separators and brackets - Engine Color
Fan - Semi-Gloss Black
K-Frame
Torsion Bars
Tie Rod ends - Natural
Steering link - Natural
Radiator......Black

I can post a spread sheet later of all the different types of black (flatness) for the black parts.

IP Logged

Kowal 4 BBL/Pack Member Posts: 164	Re: Plated, Painted or Natural Reply #23 - 07/26/09 at 20:07:30 For parts being left natural, I highly recommend Loctite Rust Preventer in a spray can. Great stuff, oderless, invisible residue, does wash off if you are caught in the rain but easy to reapply. I have had no rust starting on my natural metal parts while using this stuff.
Back to top	'69 Superbee, A12, V2 Orange '69 Road Runner, A12, R4 Red (#280) "P.J. O'Rouke: The old car ran perfectly, right up until it didn't." IP Logged
